Technical Parameters

• Gas Detection：Flammable gas (EX), imported catalytic combustion flammable gas sensor
• Detection Range:0-100%LEL
• Resolution:0.1%LEL

• Detection Accuracy:≤±3%

  Response Time≤20S（T90）

• Linearity Error：≤±1%

  Zero Drift：≤±1%（F.S/Year）

• Recovery Time：≤20S

  IP Rating：IP66

• Repeatability：≤±1%

  Intrinsic Safety：CNEx16.0537

• Scalable Gas Sensor ：User can customize 1-12 gas sensors in any combination
• Dust Sensor：Laser dust sensor is optional（0.3/0.5um、1.0um、2.5um、10um）
• Temperature and Humidity(Optional)：Temperature detection range:-40 ～ 120℃ Humidity detection range:0-100%RH
• Detection method：pump suction, built-in miniature air pump
• Detection Pattern：real-time detection mode, timing detection mode and cycle detection mode can be switch freely
• Storage Method：automatically saving and manually saving is available, up to 369,600 groups of data ,user can view history data on the display.
• Print Mode：automatic print and manual print are available, user can reset the print cycle. micro printer print data is optional
• Operating Condition： Operating Temperature: -30 ～ 60℃
  Operating Humidity ≤95%RH，Non-condensing
  Operating Pressure: -30Kpa ～ 100Kpa
  Power: 6000mA high capacity polymer rechargeable battery
• Dimensions / Weight：255*130*255 mm（L×W×H）3.3 Kg（net weight）
• Standard Accessories：instrument case, manual, certificate, USB charger,
• Optional Accessories：micro printer, Bluetooth printer,-PM2.5 laser dust particle sensor,addition of various types of sensors, GPRS module
• Production License：Guangdong Manufactured 00000052 (CMC China Metrology Certification)
• Executive Standard： GB3836.1-2010 "Explosive Environment Part 1: general requirements for equipment"
  GB3836.4-2010 "Explosive Environment Part 4: equipment protected by  intrinsically safe "i""
