Product Specification

• Gas Detection： Formaldehyde（CH2O），Imported electrochemical sensors
• Detection Range： 0-10ppm、50ppm、100、500、1000ppm（optional)
• Resolution： 0.001ppm（0-10ppm）、0.01ppm（0-100ppm）、1ppm(0-1000ppm)

• Detection Accuracy: ≤±3%

  Response time： ≤20S（T90）

• Linearity Error： ≤±1%

  Zero Drift： ≤±1%（F.S/Year）

• Recovery Time： ≤20S

  IP Rating:： IP66

• Repeatability： ≤±1%

  Intrinsically Safe： CNEx16.0537

• Scalable Gas Sensor： User can customize 1-12 gas sensors in any combination
• Dust Sensor： Laser dust sensor is optional（0.3/0.5um、1.0um、2.5um、10um）
• Temperature and Humidity(Optional)： Temperature detection range:-40 ～ 120℃ Humidity detection range:0-100%RH
• Detection method： pumping, built-in miniature air pump
• Detection Pattern： real-time detection mode, timing detection mode and cycle detection mode can be switch freely
• Storage Method： automatically saving and manually saving is available, up to 369,600 groups of data ,user can view history data on the display
• Operating Condition： Operating Temperature: -30 ～ 60℃
  Operating Humidity ≤90%RH，Non-condensing
  Power: 6000mA high capacity polymer rechargeable battery
• Dimensions / Weight： 255*130*255 mm（L×W×H） 3.3 Kg（net weight）
• Standard Accessories： instrument case, manual, certificate, USB charger,
• Optional Accessories： micro printer, Bluetooth printer,PM2.5 laser dust particle sensor,addition of various types of sensors, GPRS module
• Production License： Guangdong Manufactured 00000052 (CMC China Metrology Certification)
• Executive Standard： GB3836.1-2010 "Explosive Environment Part 1: general requirements for equipment"
  GB3836.4-2010 "Explosive Environment Part 4: equipment protected by intrinsically safe "i""
